t-beam

Solution to Problem 572 | Horizontal Shearing Stress

572 Wooden T-beam Made From Rectangular Beams

Problem 572

The T section shown in Fig. P-572 is the cross-section of a beam formed by joining two rectangular pieces of wood together. The beam is subjected to a maximum shearing force of 60 kN. Show that the NA is 34 mm from the top and the INA = 10.57 × 106 mm4. Using these values, determine the shearing stress (a) at the neutral axis and (b) at the junction between the two pieces of wood.



Solution to Problem 561 | Built-up Beams

561 T-beam strength Investigation

Problem 561

A T section has the dimensions given in Fig. P-561. Show that the neutral axis is 3 inches below the top and that INA = 166.7 in4. If the tensile stress at the bottom of the flange is 1000 psi, calculate (a) the total tensile force in the flange and (b) the total compressive force in the cross section. Also compute (c) the moment of the compressive force about the NA, and (d) the moment of the total tensile force about the NA. (e) How does the sum of (c) and (d) compare with the total applied bending moment as computed from the flexure formula?



Solution to Problem 558 | Unsymmetrical Beams

Problem 558

In Prob. 557, find the values of x and wo so that wo is a maximum.



Solution to Problem 557 | Unsymmetrical Beams

557 Overhanging Inverted T-Beam with Rectangular Symmetrical Load

Problem 557

A cast-iron beam 10 m long and supported as shown in Fig. P-557 carries a uniformly distributed load of intensity wo (including its own weight). The allowable stresses are fbt ≤ 20 MPa and fbc ≤ 80 MPa. Determine the maximum safe value of wo if x = 1.0 m.



Solution to Problem 556 | Unsymmetrical Beams

556 Overhanging Inverted t-beam with Symmetrical Concentrated Loads

Problem 556

A T beam supports the three concentrated loads shown in Fig. P-556. Prove that the NA is 3.5 in. above the bottom and that INA = 97.0 in4. Then use these values to determine the maximum value of P so that fbt ≤ 4 ksi and fbc ≤ 10 ksi.



Solution to Problem 555 | Unsymmetrical Beams

555 Overhang T-beam with Concentrated and Unifom Loads

Problem 555

A beam carries a concentrated load W and a total uniformly distributed load of 4W as shown in Fig. P-555. What safe value of W can be applied if fbc ≤ 100 MPa and fbt ≤ 60 MPa? Can a greater load be applied if the section is inverted? Explain.



Solution to Problem 554 | Unsymmetrical Beams

554 Overhang Inverted T-beam with Concentrated Loads

Problem 554

Determine the maximum tensile and compressive stresses developed in the overhanging beam shown in Fig. P-554. The cross-section is an inverted T with the given properties.



Solution to Problem 553 | Unsymmetrical Beams

553 T-beam with moment and concentrated loads

Problem 553

Determine the maximum tensile and compressive bending stresses developed in the beam as shown in Fig. P-553.



Solution to Problem 552 | Unsymmetrical Beams

552 Inverted T-section of Cantilever Beam

Problem 552

A cantilever beam carries the force and couple shown in Fig. P-552. Determine the maximum tensile and compressive bending stresses developed in the beam.



Solution to Problem 548 | Unsymmetrical Beams

548 Inverted T-section

Problem 548

The inverted T section of a 4-m simply supported beam has the properties shown in Fig. P-548. The beam carries a uniformly distributed load of intensity wo over its entire length. Determine wo if fbt ≤ 40 MPa and fbc ≤ 80 MPa.
